Model | 020460 | 020472 |
Length（mm） | 980 | 980 |
Width (mm) | 1800 | 2090 |
Height (mm) | 630 | 675 |
Vibration wheel diameter(mm) | Φ446 | Φ446 |
Theoretical weight （Kg） | 815 | 860 |
Excited force （KN）@（L/Min） | 31 @ 60 | 37 @ 60 |
Vibration velocity（Vpm） | 2600 | 2600 |
Swing Angle（°） | ±15 | ±15 |
Work flow（L/Min） | 60-70 | 60-70 |
Maximum allowable pressure（MPa） | 20 | 20 |
Adapted models | Skid steer loader/Small loader | |
Main features of the products:
1. The hydraulic system of this product is equipped with a motor protection device to prolong the service life of the motor.
2. Compared with large rollers, this product has the characteristics of flexible and simple operation, small ground occupation and less capital investment.
3. PD wheel compaction equipment has large unit pressure, uniform compaction, large compaction degree, especially for hard clay, especially suitable for compaction of cohesive soil and gravel layer.
4. When adapting to a small loader, please install the customer (bucket, bucket) limit block according to the situation of the host.
